Simplecom KM470 2-Port USB-C KVM Switch 8K Docking Station HDMI 2.1 DP for Laptop Tablet

Product Description

Simplecom KM470 2-Port USB-C KVM Switch 8K Docking Station HDMI 2.1 DP for Laptop Tablet Features USB-C KVM switch allows two laptops to share external display and USB devices Intergraded USB-C docking station, single USB-C cable for Video, Data and PD charging With both DisplayPort and HDMI output ports for TV or monitors 3-Port USB 2.0 hub for connecting mouse, keyboard, printer and more 3.5mm audio jack for connecting headphones or speakers Two PD charging ports allow charging for both laptops simultaneously HDMI 2.1 and DP 1.4 compliant, support video resolution up to 8K Backward compatible with HDMI 2.0 and HDMI 1.4 Easy to use by pressing the toggle button on the KVM switch Self-powered via connected laptop, no external power required Plug and play and hot swappable Durable aluminium alloy casing, also efficiently dissipate heat LED light indicating the active computer and PD charging Specifications Model: KM470 USB Upstream Ports: USB-C x2 (Connect to PC1 and PC2) USB Downstream Ports: USB 2.0 x3 (Connect USB peripherals) PD Charing Port: USB-C x2 (up to 100W on each port) Video Output: HDMI 2.1 x1, DP 1.4 x1 USB Max Bandwidth: HighSpeed 480Mbps HDMI Max Bandwidth: 48Gbps DP Max Bandwidth: 32.4Gbps Video Resolution: 1080p@60/120/165Hz, 4K@60/120/144Hz (DSC), 8K@30/60Hz(DSC) Audio Output: 3.5mm audio jack (sound output only) Operating Temperature: 0 to 50°C Dimension (L x W x H): 13 x 6.3 x 1.6mm Weight: 109g Operating System Support: Windows, MacOS, Chrome OS Package Contents 1x USB-C KVM Switch 2x USB-C to USB-C Cables System Requirements Laptop or mobile device with full functional USB-C port that supports DP Alt Mode (DisplayPort Alternate Mode) Laptop with Thunderbolt 3, Thunderbolt 4, USB4 port Important Note
