APC Netshelter Rack Automatic Transfer Switch, 1U, 16A, 230V, 2 IEC309 IN, 1 IEC309 OUT, 50/60Hz

Product Description

APC Netshelter Rack Automatic Transfer Switch, 1U, 16A, 230V, 2 IEC309 IN, 1 IEC309 OUT, 50/60Hz APC NetShelter Rack Automatic Transfer Switch (ATS) AP4422A is the Fifth-Generation range of high availability switches offering greater control of your IT equipment from Cloud to Edge. With Industry leading reliability, agility, and manageability the APC NetShelter Rack ATS provides redundant power to single-corded equipment loads in the IT rack. AP4422A is single phase 1U Rack ATS with 16A rated current, 230V rated voltage and 3840VA load capacity. It comes with 2 IEC 309 inlet and 1 IEC 309 outlet sockets. This has been upgraded with APC NMC3 and various technical advancements for network port sharing, environmental monitoring and enhanced security. Main Input Voltage 230 V AC 1 phase Product or component type Automatic transfer switch Main Output Voltage 230 V AC 1 phase Input Connection Type IEC 60309 16 A 2P + E Number of rack unit 1U Cable length 2.4 m Number of cables 2 Provided equipment Mounting hardware, Rack mounting brackets Network frequency 50/60 Hz [In] rated current 16 A Permissible voltage 207…253 V Max line current 16 A Input current limits 16 A Load capacity 3840 VA Number of power socket outlets 1 IEC 60309 16 A 2P + E Number of power socket outlets 1 Protection type Without circuit breaker Power cable length 0.91 m Product certifications-CE, EMC directive 2004/108/EC, LVD directive 2006/95/EC Standards EN/IEC 60950-1, UL 60950-1 Ambient air temperature for operation -5…45 °C Relative humidity 5…95 % Operating altitude 0...10000 ft ambient air temperature for storage -25…65 °C Storage Relative Humidity 5…95 % Storage altitude 0…15240 m
